Wisdomshow WDS-620 Triple-Zone Optical Alignment BGA Rework Station
Our WDS-620 BGA Rework Station is engineered for precision replacement and repair of BGA chips in laptops, mobile phones, gaming consoles (Xbox 360, PS3), and various consumer electronics. This industrial-grade solution is ideal for repair shops and electronic manufacturing facilities requiring high-precision rework operations and reliable after-sales service.
Key Features
BGA Rework Station Model: WDS-620
- Automatic & Manual operation system
- 5 million pixel CCD camera optical alignment system with ±0.01mm precision
- MCGS touch screen control interface
- Integrated laser positioning system
- 99.99% repair success rate
Precision Optical Alignment System
Features high-definition adjustable CCD color optical alignment with beam split, amplification, reduction, fine adjustment, and auto-focus capabilities. Includes automatic color aberration resolution, brightness adjustment, and contrast control. Equipped with 15" high-definition LCD monitor for optimal visibility.
Multi-Functional Operation System
1. High-definition touch human-machine interface with integrated upper heating head and mounting head design. Multiple titanium alloy BGA nozzles available with 360-degree rotation for easy installation and replacement.
2. X, Y, and R angle micrometer fine-tuning provides accuracy positioning with precision reaching ±0.01mm.
Advanced Safety Protection
Integrated alarm system automatically signals completion of BGA welding. Dual over-temperature protection with automatic circuit power-off during temperature abuse. Temperature parameters feature password protection to prevent unauthorized modifications.
BGA Repair Process
How to Separate BGA Chip from Motherboard
- Separate BGA chip from motherboard (Desoldering)
- Clean pad surface
- Reball or replace with new BGA chip
- Alignment/Positioning using experience, silk frame, or optical camera
- Install new BGA chip (Soldering)
Product Parameters
Detailed Product Images
Packing & Shipping
- Standard export wooden cases
- Delivery within 2 workdays after payment confirmation
- Shipping via TNT, DHL, FEDEX, air, or sea freight
- Loading port: Shenzhen or Hong Kong
Company Information
Shenzhen Wisdomshow Technology Co., Ltd. was founded in 2011 by experienced engineers and sales professionals. Specializing in BGA rework stations and X-RAY inspection equipment, the company has expanded through continuous R&D and innovation. With ISO9001 and CE certifications, multiple patents, and strong customization capabilities, Wisdomshow serves clients across Asia, Europe, and North America in server motherboard repair, LED assembly, and smartphone production.
Our Advantages and Service
Contact: 24-hour technical support via email or phone
Warranty: One year free warranty (other relative costs borne by buyer)
Technology Support: Demo operation videos for training; On-site demonstration available
Service: Comprehensive English user manual; Professional after-sales service
Price: Competitive pricing with significant discounts for agencies
